Description
BAUMER PROXIMITY UNDK-30I6103/S14, 10129046 - Ultrasonic distance measuring sensors
| general | |
|---|---|
| scanning range Sd | 100 … 1000 mm |
| scanning range close limit Sdc | 100 … 1000 mm |
| scanning range far limit Sde | 100 … 1000 mm |
| repeat accuracy | < 0,5 mm |
| resolution | < 0,3 mm |
| response time ton | < 80 ms |
| release time toff | < 80 ms |
| temperature drift | < 2 % of distance to target So |
| sonic frequency | 240 kHz |
| adjustment | Teach-in |
| alignment aid | target indication flashing |
| light indicator | yellow LED / red LED |
| electrical | |
| voltage supply range +Vs | 15 … 30 VDC |
| current consumption max. (no load) | 55 mA |
| output circuit | current output |
| output signal | 4 ... 20 mA / 20 ... 4 mA |
| output current | < 20 mA |
| load resistance +Vs max. | < 1100 Ohm |
| load resistance +Vs min. | < 400 Ohm |
| residual ripple | < 10 % Vs |
| short circuit protection | yes |
| reverse polarity protection | yes |
| mechanical | |
| type | rectangular |
| housing material | polyester / die-cast zinc |
| width / diameter | 30 mm |
| height / length | 65 mm |
| depth | 31 mm |
| connection types | connector M12 |
| ambient conditions | |
| operating temperature | -10 … +60 °C |
| protection class | IP 67 |
New - These products are brand new in box, sealed where applicable. Units are covered by original equipment manufacturer (OEM) warranty as applicable.
