S8-PR-5-W03-PP

Datalogic S8-PR-3-W03-PP, Plastic Contrast High Performance Photoelectric Sensor, PNP, M12 pig-tail compact, high-performance photoelectric contrast sensor from the S8 series, designed for detecting color marks in industrial automation, particularly for packaging and printing applications. It features RGB LED emission for precise contrast detection and IO-Link connectivity for Industry 4.0 integration

• Light Source: RGB LEDs (Blue: 465 nm, Green: 520 nm, Red: 630 nm, auto-select)
• Sensing Distance: 10 mm ± 2 mm
• Spot Size: 3 x 1 mm
• Switching Frequency: Up to 25 kHz
• Output: PNP, Light/Dark selectable (NO/NC)
• Connection: M12 4-pin pigtail
• Supply Voltage: 12–30 VDC
• Dimensions: 14 x 42 x 25 mm
• Material: Plastic ABS/PMMA housing
• Protection: IP67
• Temperature Range: -10°C to +55°C
• Features: Background suppression for shiny/transparent objects, IO-Link COM2, dual-channel, extended parametrization with counter, high-resolution detection
• Applications: Packaging lines, food/beverage, printing, electronics
• Certifications: CE, UL

** New - These products are new in box, sealed where applicable. Units are covered by 12 month conditional warranty
