Description
INA NKX15-Z-XL Needle Roller/Thrust Ball Bearing - 15mm ID, 24mm OD, 23mm Width, Single Direction, Z Shield, X-Life. High-capacity, compact bearing for radial and axial loads in industrial applications.
- Type: Needle roller/axial ball bearing, single direction, with end cap (Z shield), for grease lubrication
- Dimensions:
- Inner Diameter (d): 15 mm (0.5906 in)
- Outer Diameter (D): 24 mm (0.9449 in)
- Width (B): 23 mm (0.9055 in)
- Weight: 0.047 kg (0.1036 lb)
- Load Ratings:
- Radial Dynamic Load Rating (Cr): 12,100 N
- Radial Static Load Rating (C0r): 12,700 N
- Axial Dynamic Load Rating (Ca): 10,500 N
- Axial Static Load Rating (C0a): 16,800 N
- Limiting Speed (nG): 9,500 rpm
- Seal: Z shield (pressed sheet steel on one side for grease retention)
- Standards: DIN 5429
- ECLASS Number: 23-05-12-02
- Features:
- Combines needle roller bearing for radial loads and thrust ball bearing for axial loads
- X-Life design for higher load capacity and longer service life
- Compact, low-profile construction for space-constrained applications
- Non-separable design for easy installation
- Suitable for grease lubrication
- Applications: Industrial machinery, automation systems, gearboxes, and applications requiring combined radial and axial load support
- Manufacturer Part Number: 0507475680000
- EAN: 4012802733174
** New - These products are new in box, sealed where applicable. Units are covered by 12 month conditional warranty
