ESBE VRG131 (11603400)

ESBE VRG131 (11603400) 3-way mixing valve from the VRG130 series, designed for mixing or diverting operations in heating, cooling, and tap water systems. Made of high-performance DZR brass, it ensures low leakage and durability.

• Type: 3-way mixing/diverting valve
• Connection: Rp 1-1/2" (DN40) internal thread
• Kvs Value: 25 m³/h
• Pressure Rating: PN10 (max. 10 bar)
• Media Temperature: -10°C to +110°C (continuous), +130°C (temporary)
• Material: DZR brass body, EPDM O-ring seals
• Operation Angle: 90° (adjustable to 360° for porting configuration)
• Torque: 5 Nm
• Features: Non-slip adjustment knob, low leakage (<0.05%), compatible with ESBE actuators (e.g., ARA series) and controllers
• Applications: Heating, cooling, and tap water installations
• Replaces: Part numbers 11050400, 11601300

** New - These products are new in box, sealed where applicable. Units are covered by 12 month conditional warranty
