3RW3036-1AB05 - Pre-Owned Part, See Description

• ype: SIRIUS 3RW30 Soft Starter
• Size: S2
• Rated Operational Current: 45 A (at 40°C)
• Rated Power: 22 kW at 400 V (for three-phase motors)
• Operational Voltage: 200–460 V AC
• Control Supply Voltage: 110–230 V AC/DC
• Connection: Screw terminals
• Frequency: 50/60 Hz
• Short-Circuit Protection: 5 kA at 600 V
• Torque Rating: 7 Nm at low speeds, up to 10.3 Nm at higher speeds
• Mounting: DIN rail or panel mounting
• Protection Rating: IP20
• Operating Temperature: -25°C to +60°C
• Weight: Approximately 0.787 kg
• Dimensions: Approx. 170 mm (H) x 55 mm (W) x 152 mm (D)
• Standards: CE, UL, CSA, compliant with IEC 60947-4-2
• Applications: Soft starting for three-phase motors in pumps, fans, conveyors, and other industrial systems
• Features:
• Variable phase control to reduce motor voltage and torque during startup
• Smooth ramp-up to mains voltage, minimizing mechanical loads and voltage dips
• Compact design for easy integration into control panels
• Adjustable starting voltage for application-specific control
• Suitable for inline circuit configurations

** U - Pre-Owned Part - previously used in an automation system or may have been used or tested offline or R&D units. Items are fully functional. Condition can vary but items are cleaned and inspected before dispatch. 12 Month Warranty
